Operating voltage
|
230V AC +/-10%, 50/60 Hz or
115V AC +/-10%, 50/60 Hz |
Relay contacts |
2 voltage-free make-contacts |
max. switching current |
12 A AC1 each |
max. switching voltage |
250 V ~ |
Display |
13 mm LED - Display, 3 digits |
Display range |
-99 .. 999 |
Resolution
- Range -9,9 .. 50°C
- other
|
0.1°C
1.0°C
|
Sensor type |
KTY 81-210 |
Sensor cable lenght |
2 metres (or as required) |
Target temperature T1*
Target temperature T2* |
standard adjusting 8°C
standard adjusting 4°C |
Control type |
two-step regulator |
Hysteresis* |
0,1 K .. 99,9 K
(standard adjusting 0,7 K) |
Stirrer
- resting time (interval) *
- stirring time * |
factory-set to 20 min.
factory-set to 2 min.
|
Housing
- Front measure
- Control panel cutout
- Depth |
48 x 96 mm
42 x 90 mm
88 mm
|
Protection (housing front) |
IP 64 |
Connection |
Screw terminals |
Environment specifications:
- Operation temperature
- Storage temperature
- max. humidity |
0° .. +50°C
-20° .. +70°C
75% (no dew)
|
|
* freely adjustable |
